Karl Fischer Water Content Tester Model TP-009A
Home » Products » Petroleum Tester » Petroleum Products General Testers » Karl Fischer Water Content Tester Model TP-009A

Category List

Share to:

Karl Fischer Water Content Tester Model TP-009A

  • TP-009A
  • CHONGQING TOP
Availability:
Quantity:

Product Description

Application:

TP-009A Karl Fischer Water Content Tester is designed and manufactured in accordance with GB/T 260-2016. It is suitable for determining the water content in petroleum products. The random configuration includes the necessary parts for the test which can be completed without additional spare parts.



Features:

The instrument consists of the flask, the receiver, the condenser, the heating jacket, the temperature adjustment device, the clamping device, etc.

The heating jacket is made of glass fiber, which has good heat preservation performance. Its hemispherical shape makes the flask be heated evenly with high thermal efficiency.

The temperature adjustment device is simple to use, easy to install, and has good reliability. The output voltage is adjusted by a potentiometer and indicated by a voltmeter, which is intuitive and practical.

The clamping device is composed of a pole support, a cross clamp and a universal clamp. The height of the clamp can be adjusted on the pole support as required.



Technical parameters:

Heating jacket power: duplex 470W×2

Heating power adjustment range: 0470W continuously adjustable

Flask: 1000ml

Weight: 8kg



Testable items of instrument configuration:

It is suitable for measuring the water content in petroleum products.

Accessories configuration (including manufacturer) (single unit):

Serial Number

Name and Specification Model

Quantity

Remarks

1

Host TP-009A

1 set

Duplex

2

Fuse Φ6×30  10A

1 pc


3

Flask 500ml

2 pcs


4

Condenser pipe

2 pcs


5

Receiver

2 pcs


6

Cross clamp, universal clamp

2 sets


7

Pole support

2 pcs


8

Silicone tube φ8*12

2m
